NX 200
Specifications​
Body Dimensions
Type :
4 Stroke, SI Engine
Displacement :
184.4 cc
Max Engine Output :
NA
Max Net Torque :
15.7 N-m @ 6000 rpm
Max Net Power :
12.5 kW @ 8500 rpm
Fuel System :
PGM-Fi
Bore X Stroke :
61.0 x 63.096
Compression Ratio :
9.5:1
Starting Method :
Self Start
Engine
Kerb Weight :
148 kg
Length :
2035 mm
Width :
843 mm
Height :
1248 mm
Wheelbase :
1355 mm
Ground Clearance :
167 mm
Seat Height :
810 mm
Seat Length:
613 mm
Transmission
No Of Gears :
5
Clutch Type :
Multiplate Wet Clutch
Tyres & Brakes
Front tyre Size & Type :
110/70-17 M/C 54S
Rear Tyre Size & Type :
140/70-17 M/C 66S
ABS :
2 Channel ABS
Fornt Brake Type & Size :
Disc 276 mm
Rear Brake Type & Size :
Disc 220 mm
Frame & Suspension
Frame Type :
Diamond type
Front Suspension :
Upside Down Front Fork (USD)
Rear Suspension :
Monoshock
Electricals
