Shine 100 DX
Specifications​
Body Dimensions
Type :
4 Stroke, SI Engine, BS-VI
Displacement :
98.98 cc
Max Engine Output :
5.43 kW @ 7500 rpm
Max Net Torque :
8.05 Nm @ 5000 rpm
Max Net Power :
NA
Fuel System :
PGM-FI
Bore X Stroke :
47.0 X 57.049 mm
Compression Ratio :
10.0:1
Starting Method :
Self/Kick start
Engine
Kerb Weight :
103 Kg
Length :
1955 mm
Width :
754 mm
Height :
11050 mm
Wheelbase :
1245 mm
Ground Clearance :
168 mm
Seat Height :
677 mm
Seat Length:
786 mm
Transmission
No Of Gears :
4
Clutch Type :
Multiplate Wet Clutch
Tyres & Brakes
Front tyre Size & Type :
2.75 -17 M/C 41P, Tubeless
Rear Tyre Size & Type :
3.00 – 17 M/C 50P, Tubeless
ABS :
NA
Fornt Brake Type & Size :
Drum – 130 mm
Rear Brake Type & Size :
Drum – 110 mm
Frame & Suspension
Frame Type :
Diamond Type
Front Suspension :
Telescopic
Rear Suspension :
Twin (5-Setps Adjustable)
Electricals
